What Is Glulam?
Glued laminated timber, also known as glulam or GLT, is a type of engineered wood product made by bonding together several layers of dimensional lumber with high-strength adhesive. Glulam can be used in a number of building applications, including use as supporting members for roofs and floors, structural columns, and arches. The bonding adhesive used to make glulam is usually a type of moisture-resistant resin, such as phenol formaldehyde or melamine formaldehyde. This ensures that glulam beams remain stable even in damp or humid conditions, and many glulam products are rated for exterior or industrial exposure under ANSI A190.1 standards.
Glulam is produced in a wide range of standard sizes and shapes to suit different design requirements, but a big attraction of glulam is that it can also be custom-made for specific projects. Curved or angled glulam members can be created by bending or cutting the individual pieces before they are bonded together. This means that glulam can help realize unique architectural designs, such as dramatic arches or long-span roof beams. Glulam beams can be used for spans of more than 100 feet.
Typical density values for glulam range between 32 and 40 pounds per cubic foot (513–641 kg/m³), depending on the wood species used. The weight values produced by the calculator and shown in the table below derive from a set value of 35 pounds per cubic foot, which is consistent with commonly published APA and manufacturer data.
Wood Types, Dimensions, and Standard Weight of Glulam
Glulam beams in the United States are most commonly manufactured from two species groups: Douglas-fir and Southern Pine. Both species are covered under ANSI A190.1, the national consensus standard for glulam production, and are widely available in standard grades such as 24F Douglas-fir and 24F Southern Pine.
Standard glulam beam dimensions follow a limited set of nominal thicknesses and depths rather than being completely arbitrary. Many stock beams are manufactured in standardized thicknesses of 3-1/8 inches, 3-1/2 inches, 5-1/8 inches, 5-1/2 inches, 6-3/4 inches, 8-3/4 inches, and 10-3/4 inches, with depths ranging upward from 6 inches to 48 inches or more in 1-1/2 inch increments. These dimensions are standardized so that glulam can integrate smoothly with common framing layouts and structural requirements.
The standard design tables published by the APA use a reference density of 35 pounds per cubic foot (pcf) for calculating beam weights. In practice, actual beam weight depends on wood species and moisture content, but engineers and manufacturers commonly use 35 pcf as the baseline density for glulam beams.
Beam Dimensions
The terms “thickness” and “depth” may be slightly confusing. Here’s a diagram so you know what thickness and depth refer to.
Example: Glulam beam 3.5″ thickness × 10″ depth.
Glulam Beam Weight & Volume Calculator
This calculator assumes a density for glued laminated timber of 35 pounds per cubic foot (pcf). There are glulam products that vary from this weight value, so you should always check the manufacturer’s technical data sheet for the exact product you intend to use. You can change the density used by the calculator with the “Glulam density” input.
This calculator takes decimal or fractional inputs for beam width and depth. When entering a thickness or depth greater than 1 that contains a fraction, such as 3 1/2, make sure to include a space between the whole number and the fraction. Type in “3 1/2”, not “31/8”.
About the Glulam Weight Table
The following table provides the approximate weight (dead load, self-weight) for glulam beams used in building construction in the U.S. The table provides the weight per cubic foot as well as the weight per linear foot for various dimensions of glulam members. The values given in the table are meant to provide a general idea of typical weights for glulam beams, and should not be used if precise values are needed for critical engineering calculations.
I also provide weights for dimensions (such as 1/4 inch) that are not the actual dimensions of any real glulam beam. I did this to make it easier to use the table to calculate weights for custom beam dimensions that don’t have published standard weights and are not listed in the tables.
Remember: When precision is necessary, always refer to the specification sheet for the actual product you intend to use, or contact the technical department of the manufacturer.
Table: Glued Laminated Timber (Glulam) Weights
Glulam typically weighs around 35 pounds per cubic foot, or about 3 pounds per board foot. (The trick is to figure out how many cubic feet are in the beam.)
| Weight of Glulam (Glued Laminated Timber) | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 35 Pounds per Cubic Foot (lbs/ft3) | ||||||||||||||
| 2.92 Pounds per Board Foot | ||||||||||||||
|
Table Shows Weight per Linear Foot for Standard Glulam Beam Thicknesses (1 inch is not a standard thickness) and a Sample of Glulam Beam Depths |
||||||||||||||
|
Glulam is not typically manufactured in thicknesses or depths of less than 3 inches. Weights for dimensions smaller than 3 inches are included to make it easier to calculate weights for custom beam sizes not included in the table. |
||||||||||||||
| Thickness of Beam in Inches |
Depth (Height) of Beam in Inches | |||||||||||||
| ↓ | 1/8 inch | 1/4″ | 3/8″ | 1/2″ | 5/8″ | 3/4″ | 7/8″ | 1″ | 2″ | 3″ | 4″ | 5″ | 10″ | 20″ |
| 1 inch | 0.03 lbs | 0.07 | 0.09 | 0.13 | 0.16 | 0.18 | 0.21 | 0.24 | 0.49 | 0.73 | 0.97 | 1.22 | 2.43 | 4.86 |
| 3-1/8″ | 0.1 lbs | 0.19 | 0.28 | 0.38 | 0.48 | 0.57 | 0.66 | 0.76 | 1.52 | 2.28 | 3.04 | 3.8 | 7.59 | 15.2 |
| 3-1/2″ | 0.11 lbs | 0.21 | 0.32 | 0.43 | 0.53 | 0.64 | 0.75 | 0.86 | 1.7 | 2.56 | 3.4 | 4.26 | 8.51 | 17.01 |
| 5-1/8″ | 0.16 lbs | 0.31 | 0.47 | 0.62 | 0.78 | 0.93 | 1.09 | 1.24 | 2.49 | 3.73 | 4.99 | 6.23 | 12.45 | 24.92 |
| 5-1/2″ | 0.17 lbs | 0.33 | 0.51 | 0.67 | 0.84 | 1 | 1.17 | 1.34 | 2.67 | 4.02 | 5.35 | 6.69 | 13.37 | 26.74 |
| 6-3/4″ | 0.2 lbs | 0.41 | 0.61 | 0.82 | 1.03 | 1.24 | 1.44 | 1.64 | 3.29 | 4.92 | 6.56 | 8.21 | 16.41 | 32.81 |
| 8-3/4″ | 0.26 lbs | 0.53 | 0.8 | 1.06 | 1.33 | 1.59 | 1.86 | 2.13 | 4.26 | 6.38 | 8.51 | 10.64 | 21.27 | 42.53 |
| 10-3/4″ | 0.33 lbs | 0.65 | 0.98 | 1.3 | 1.63 | 1.96 | 2.28 | 2.62 | 5.23 | 7.84 | 10.45 | 13.07 | 26.13 | 52.26 |
Further Information about Glulam
To learn more about glulam, visit the websites of the APA (Engineered Wood Association) and the AITC (American Institute of Timber Construction). They have detailed information about engineered wood applications, beam sizing, design tables, product guides, and more. You may need to create a free account with them in order to access the publications (in PDF) that contain the most detailed technical information.
In particular, for technical data covering the physical properties of glulam beams, including weight per foot and allowable loads, see Glued Laminated Beam Design Tables. (This is a document produced by the APA but made available on the International Code Council website. Use the table of contents on the left side of the screen to view the different sections.)
